型号：G2260-150T73U

封装：SOT-23-3

品牌：GMT/致新

温馨提示：由于公司产品型号较多，如有具体需求可直接致电或QQ联系！

描述

G2260是一款低压差线性稳压器，具有超-低电流消耗和高输出电压精度。空载时的电源电流通常为1μA。内置的低导通电阻实现了低压差和高输出电流。最小输出电流限制设置为250mA。G2260设计用于使用小至0.1μF的I/O电容器，并采用节省空间的SOT-23-3、SOT-23-5、UDFN1X1-4封装。

特征

● 通常为1μA空载电源电流

● 保-证250mA输出电流（3.0V输出@VIN≥VOUT+1V）

● 输入电压范围：2.5V~6.5V

● 1.5V~5.0V输出电压

● 压降电压为150mV@100mA负载

● 内置过电流保护

● 稳定的低成本陶瓷电容器

应用

● 电池供电设备的电源

● 手机和其他便携式设备

产品规格书（部分），如需PDF文档请QQ索要或电话联系
