深圳市科瑞芯电子有限公司为GMT/致新正规代理商，商品原装

供应超-低电流消耗和低压差线性稳压器，可免费提供样品及技术支持！

深圳市内可送货上门，欢迎致电！

型号：G2260-180T11U

封装：SOT-23-5

品牌：GMT/致新

温馨提示：公司产品丰富，如想求购具体型号可直接致电或QQ联系！

General Description

The G2260 is a low dropout linear regulator with ultra low current consumption and high output voltage accuracy. The supply current at no-load is typically 1μA. The built-in low-on-resistance realizes low dropout voltage and high output current. Minimum output current limit is set at 250mA. The G2260 is designed to employ I/O capacitors are as small as 0.1μF, and comes in space saving SOT-23-3, SOT-23-5, UDFN1X1-4 packages.

Features

● Typically 1μA no-load supply current

● Guaranteed 250mA output current (3.0V output@VIN ≧ VOUT+1V)

● Input voltage range: 2.5V~6.5V

● 1.5V ~ 5.0V output voltage

● Dropout Voltage is 150mV @ 100mA Load

● Built-in over-current protection

● Stable with low cost ceramic capacitors

Applications

● Power supply for battery-powered devices

● Cellular phones and other portable devices

如需详细规格书/ROHS报告/产品选型表/代理证书等资料请QQ索要或电话联系
